thickness (t) height (h) app. open area app. kg/m2 app. min. grid (p) diameter single relief waterflow direction std. width x length max. width x length
mm mm % mm mm mm mm
0.8 9.8 - max. 10.29* 22 12 // width of sheet - 1490 x on request*


-It is possible to define the grid measure yourself (excluding the range below the technical minimum).
-Larger sheet dimensions may be possible, on request.

*The weight depends on the grid.
**Max. length depends on the grinding direction and the grid.
