| thickness | height app. | frontal open area app. | material | kg/m2 app. | max. width x length | ||
| mm | mm | % | mm | ||||
| 1.5 | 7 | 5,3 | Steel | 11.7 | 1500 x 3000 or 2500 x 1500 | ||
| Aluminium | 3.9 | 1500 x 3000 or 2500 x 1500 | |||||
| 2 | 8 | 5,3 | Steel | 15.6 | 1500 x 3000 or 2500 x 1500 | ||
| Aluminium | 5.2 | 1500 x 3000 or 2500 x 1500 |
