thickness (t) height (h) app. open area app. kg/m2 app. min. grid (p) diameter single relief waterflow direction std. width x length max. width x length
mm mm % mm mm mm mm
1 10 - max. 4.42* 22 12 // width of sheet 1450** x 1738 or 2990** x 814 2990** x on request*


-It is possible to define the grid measure yourself (excluding the range below the technical minimum).
-Larger sheet dimensions may be possible, on request.

*The weight and max. length depend on the grid.
**If the width is more dan 1.450 mm the length additionally has 2x 50 mm plain edges, needed for anodising.
