| thickness (t) |
height (h) app. |
open area app. |
kg/m2 app. |
min. grid (p) |
diameter single relief |
waterflow direction |
std. width x length |
max. width x length |
| mm |
mm |
% |
|
mm |
mm |
|
mm |
mm |
| 1 |
7 |
- |
max. 2.89* |
42 |
36 |
// width of sheet |
- |
2990** x on request* |
-It is possible to define the grid measure yourself (excluding the range below the technical minimum).
-Larger sheet dimensions may be possible, on request.
*The weight and max. length depend on the grid.
**If the width is more dan 1.450 mm the length additionally has 2x 50 mm plain edges, needed for anodising.
